SET Fluororesin Tube
Regular price
RM310.50
Couldn't load pickup availability
Product details
- Vendor Unipac Store
PRODUCT FEATURES
- Superior chemical resistance, best suited for chemical, food-processing, medical care, and semiconductor applications.
- Achieved 44% cost reduction compared to Pisco SFT Fluororesin (PFA) Tube series.
- Extensive service temperature range.
- Tube softness/hardness: Soft / Somewhat soft / Somewhat hard / Hard
- Fluid admitted: Air, water (conditional), chemicals (conditional)
- Negative pressure range: -29.5inHg (-100kPa)
- Service temperature range: -85~392°F (-65~200°C) (No freezing)
| O.D.xI.D. (mm) | Maximum pressure range (at 20°C 65% RH) | Minimum Bending Radius (mm) |
| 4x2.0 | 392psi (2.7MPa) | 7 |
| 4x2.5 | 232psi (1.6MPa) | 14 |
| 6x4.0 | 232psi (1.6MPa) | 14 |
| 8x6.0 | 145psi (1.0MPa) | 27 |
| 10x7.5 | 145psi (1.0MPa) | 40 |
| 10x8.0 | 102psi (0.7MPa) | 50 |
| 12x9.0 | 145psi (1.0MPa) | 47 |
| 12x10.0 | 102psi (0.7MPa) | 67 |
| 16x13.0 | 102psi (0.7MPa) | 94 |
| O.D.xI.D. (in.) | ||
| 1/4 x 0.18 | 145psi (1.0MPa) | 14 |
| 3/8 x 0.28 | 145psi (1.0MPa) | 40 |
| 1/2 x 0.38 | 145psi (1.0MPa) | 47 |
